Information |
||
|---|---|---|
| PD No. | iBt-250NX4KT256-M42 | |
| PD Line | iBt Series | |
Sensor |
||
|---|---|---|
| Shutter | Global | |
| Sensor Size | 20.48 mm | |
| Resolution | 4096*256 | |
| LineRate | 250kHz@8bit，237kHz@10bit，198kHz@12bit | |
| Spectral Region | 0.4-1um | |
| Exposure Time | 4μs-1s | |
Camera Data |
||
|---|---|---|
| Interface | CoaXPress | |
| Pixel Bit Depth | 8/10/12 bit | |
| Power Supply | DC12-24V(±10%) 1.0A | |
Design |
||
|---|---|---|
| Dimension | 60.0mmx 60.0mmx39.0mm | |
| Lens Mount | M42 | |
| Working Temperature | -20~75 °C (Storage), 0~55°C ( Operating ) | |
Software Environment |
||
|---|---|---|
| Driver, SDK | iBoost Kit | |
