MARS12MC-188XM-M58
  • 12MP @188 fps
  • CoaXPress uses CXP-6, theoretical bandwidth 4 x 6.25Gbps
  • Compatible with CoaXPress Protocol, GenlCam Standard, and the third-party software based on these protocol and standard
  • Support Windows operating platform
  • Support PoCXP power supply and DC 24V power supply

Inquire now
Shop now
Product Description
Technical Drawing
Documents & Downloads

Information

PD No. CP-0704
PD Line Mars Series

Sensor

Sensor Vendor CMOSIS
Sensor CMV 12000
Shutter Global Shutter
Sensor Size 22.5mm x 16.9mm
Sensor Type CMOS
Resolution 4092 px x 3072 px
Pixel size 5.5 μm x 5.5 μm
Frame Rate 188 fps
Mono/Color Mono

EMVA Data

Dynamic range 60.0 dB
Signal-to-Noise Ratio (typical) >41 dB

Camera Data

Interface CoaXPress
Pixel Bit Depth 12 bits
Synchronization

● Soft Trigger

● Hardware Trigger

● Free Run

I/O 3 configurable input and output
Power Supply 24 VDC / PoCXP

Design

Dimension (L x W x H) 72 mm x 72 mm x 72 mm
Lens Mount  M58
Working Temperature  -30 - 50°C(Operating),-30 - 80°C(Storage)

Software Environment

Driver , SDK Frame Grabber control software compliant with CoaXPress protocol
Operating System Windows
Conformity CoaxPress and GenICam
