VT-LEM0820
VT-LEM industrial lens is a high-performance and cost-effective product designed and manufactured by machine vision based on multi-year market application feedback, professional optical lens assembly and coating process, advanced optical structure, and performance and quality similar to foreign products. Comparable, the entire series reaches 5 million optical points.
Inquire now
Shop now
Product Description
Technical Drawing
Documents & Downloads

General Information

Model Number CP-1200
Series CB Series
Type Standard FA Lens

Optical Specifications

Resolution 5 Mega Pixels
Image Size 1/1.8" CCD/CMOS
Focal length 8.0 mm
Aperture, F/# F2.0
Flange Back 17.526 mm
Back Focus 11.4 mm
M.O.D 0.1 m
FOV(D×H×V)

D:46.8°

H:36.0°

V:56.0°

TV Distortion <0.1%
TTL 42.526 mm
Relative Illumination NA
Focus Range NA
Iris Manual
Focus Manual
Max. Incident Angle NA
Coating Wavelength 400-950 nm

Mechanical Parameters

Mount C-mount
Filter Size M25.5× 0.5
Built-in ir-cut NA
Front/Rear Effective Dia. FrontΦ20.1 mm / RearΦ6 mm
Dimension Φ26.8 × 25 mm
Temperature Range -10 - 50°C(Working),-20 - 60°C(Storage)
Weight NA

Standard FA industrial lens
