Information |
||
|---|---|---|
| PD No. | CP-0823 | |
| PD Line | LT3 Series | |
Input Features |
||
|---|---|---|
| Input Voltage | AC100-240V 50/60Hz | |
Output Features |
||
|---|---|---|
| Output Type | Constant Pressure | |
| Number of Channels | 1 | |
| Output Voltage | DC24V@12.5A | |
| Single Output Maximum Power | ≤300W | |
| Illuminator Port | AM20K4Z 1,2：Output-；3,4：Output+ | |
| Adjustment Mode | Button / RS232 Serial Communication | |
| Adjustment Level | 256 levels | |
Trigger Features |
||
|---|---|---|
| Trigger Delay | ≤5ms | |
| External Trigger Voltage | DC5V-24V (maximum current is about 5.6mA) | |
Protection |
||
|---|---|---|
| Activated when output current overload 110%, and will automatically recover after the overload is eliminated. | ||
Environment |
||
|---|---|---|
| Operating Temperature | Temperature: 0-40℃, Humidity:20~85%RH | |
| Storage Temperature | Temperature: -20-60℃, Humidity:20~85%RH | |
Others |
||
|---|---|---|
| Cooling Mode | Forced Cooling | |
| Environmental Regulation | RoHS | |
