Information |
||
|---|---|---|
| PD No. | CO20W | |
| PD Line | CO Series | |
|
|||||
|---|---|---|---|---|---|
|
● Molded products with compact appearance ● Able to replace 100W halogen light source |
|||||
|
|||||
|---|---|---|---|---|---|
|
● Semiconductor equipment ● Electronic device equipment ● Industrial/scientific/medical microscope applications |
|||||
Specifications |
||
|---|---|---|
| Light Guide Outlet Diameter | 8mm | |
| Brightness | Approximate 300 KXL | |
| Emitting Color | White(red, blue and green are optional) | |
| Color Temperature | 6500-7500K | |
| Input Voltage | DC24V | |
| Power Consumption | 10W | |
| Operating Environment (Indoor only) | Temperature: 0 to 40℃ , Humidity: 20% to 85%RH (with no condensation) | |
| Outside Dimension (Indoor only) | 170mm ×75mm × 100mm | |
| Weight (Indoor only) | 1.5kg | |
| Info. (Indoor only) |
*1: Test parameter : 100% brightness, emitting surface 8mm, workingdistance 50mm. *2: Depending on the operating environment, not a guarantee. |
|
