General Information |
||
|---|---|---|
| PD No. | VLEN2-0814SW-H1 | |
| PD Line | FA Series | |
| Type | SWIR Lenses | |
Optical Specifications |
||
|---|---|---|
| Resolution | 2MP | |
| Image Size | 1" CCD/CMOS | |
| Focal Length | 8 mm | |
| FOV (D/H/V) | 90.7°/78.4°/62.6° | |
| Aperture, F/# | F1.4 | |
| Back Focus | 9.65 mm | |
| Distortion | <-3.6% | |
| Iris | Manual | |
| Wavelength | 900-1700nm | |
Design |
||
|---|---|---|
| Mount | C-mount | |
| Filter Screw Size | M67×0.75mm | |
| Dimension | Φ69.5×69 mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | NA | |
