VT-LEMF4028MP29-0.01X
1. Wide wavelength from 400~950nm
2. Optical performance is superior to lens of SLR
3. Support 5μm pixel 29MP High resolution
4. High Cost Performance
Inquire now
Shop now
Product Description
Technical Drawing
Documents & Downloads

General Information

PD No. CP-0704
PD Line Large format
Type Large format F/T Mount lens


Optical Specification

Resolution 30lp/mm 5 MP
Format 43mm
Focal Length 40.0 mm
Aperature, F/# F2.8-22
Mag. Range 0.01x-0.25x
Standard Mag. 0.1x
Flange Back 46.5mm
Back Focus 436.7 mm
M.O.D 0.2 m
FOV(D×H×V)

D:65°

H:/°

V:/°

TV Distortion <0.2%
TTL 89.15
Relative Illumination NA
Focus Range NA
Iris Manual
Focus Manual
Max. Chief Ray Angle NA
Coating Wavelength 400-950 nm


Mechanical Parameters

Mount F-mount
Filter Size M62 × 0.75
Bulit-in IR-cut NA
Front/Rear Effective Dia. NA
Dimension Φ73 × 42.65 mm
Temperature Range -10- 50°C(Working),-20- 60°C(Storage)
Weight NA

Standard FA industrial lens
