General Information |
||
|---|---|---|
| PD No. | CP-1128 | |
| PD Line | Large Format Series | |
| Type |
Large Format F/T mount lenses
|
|
Optical Specifications |
||
|---|---|---|
| Resolution | 29 MP | |
| Image Size | 43.2 mm | |
| Focal length | 50.0 mm | |
| Aperture, F/# | F2.8-22 | |
| Mag. Range | 0.02x-0.1x | |
| Standard Mag. | 0.06x | |
| Flange Back | 46.5 mm | |
| Object distance | 524.4 mm | |
| M.O.D | NA | |
|
FOV(D×H×V) |
D:45.5°±3° H:/° V:/° |
|
| TV Distortion | <0.2% | |
| TTL | 82.1 | |
| Relative Illumination | NA | |
| Focus Range | NA | |
| Iris | Manual | |
| Focus | Manual | |
| Max Chief Ray Angle | NA | |
| Coating Wavelength |
400-950 nm
|
|
Mechanical Parameters |
||
|---|---|---|
| Mount | F-mount | |
| Filter Size | M62 × 0.75 | |
| Built-in ir-cut | NA | |
| Front/Rear Effective Dia. | Φ21.1 mm | |
| Dimension | Φ64 × 35.6 mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | NA | |
