Information |
||
|---|---|---|
| PD No. | CP-0704 | |
| PD Line | BTL Series | |
| Type | Bi-Telecentric Lenses | |
Lens Data |
||
|---|---|---|
| FOV | 90 Φmm | |
| Mag.(x) | 0.484x | |
| WD | 208±3 mm | |
| Max. Sesnor Size | 44 Φmm (Full frame 35mm) | |
| Field of View |
Line-2K(20.48mm) 41.9 mm Line-4K(28.67mm) 58.6 mm Line-8K(40.96mm) 83.8 mm 35mm (36.0*24.0) 73.6x49.1 mm |
|
| F/# | F11.5 | |
| MTF | >75lp/mm | |
| D.O.F | ±3.4 mm@F20 | |
| Distortion | <0.1% | |
| Telecentricity | <0.1° | |
| I/O | 561±3 mm | |
Design |
||
|---|---|---|
| Lens Mount | F-mount | |
| Length | 341.3 mm | |
| Temperature | -10 - 50°C（Operating），-20 - 60°C（Storage） | |
| Weight | 2.4 Kg | |
