Information |
||
|---|---|---|
| PD No. | CP-0823 | |
| PD Line | LT3 Series | |
Input Features |
||
|---|---|---|
| Input Voltage | AC100V-240V | |
| Drive Mode | Constant voltage | |
Output Features |
||
|---|---|---|
| Light Control | Panel buttons/RS232 | |
| Light Mode |
PWM light/ Strobe light |
|
| PWM KHz |
156.25 KHz |
|
| Suitable Light |
DC24V input light 2 channels in total 456W |
|
| Output Voltage | DC24V | |
| Output Electric Currency | 20A ( Maximum electric currency in single channel: light 9A, fan 1A) | |
| Output Power | 480W | |
| Output port |
Fan output SMP-03V-BC (1: output+; 2: NC; 3. output-) Light output 19M-2E (1: plus; 2: minus) |
|
Trigger Features |
||
|---|---|---|
| External trigger voltage | DC5V~24V(electric currency is about 5.6 mA) | |
| Trigger delay | <10us(Strobe mode)、＜40us(PWM mode) | |
| External trigger port | Locking wire terminal | |
Environment |
||
|---|---|---|
| Operating Environment | Temperature: 0-60℃, Humidity:20~85%RH | |
| Storage Environment | Temperature: -20-60℃, Humidity:20~85%RH | |
Others |
||
|---|---|---|
| Cooling Mode | Natural cooling | |
