Information |
||
|---|---|---|
| PD No. | CP- | |
| PD Line | LEO Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Sony | |
| Sensor | IMX342 | |
| Shutter | Global Shutter | |
| Sensor Size | 22.3 mm × 16.7 mm | |
| Sensor Type | CMOS | |
| Resolution | 6464 px x 4852 px | |
| Pixel size | 3.45 μm x 3.45 μm | |
| Frame Rate | 3.9 fps | |
| Mono/Color | Color | |
| Pixel format | Mono 8/10/12 Bayer RG, 8/10/10Packed/12/12Packed, YUV422Packed, YUV422_YUYV_Packed, RGB 8, BGR 8 | |
| Exposure Time |
UltraShort exposure mode: 3μs to 33μs Standard exposure mode: 36μs to 2s |
|
EMVA Data |
||
|---|---|---|
| Dynamic range | 73.0 dB | |
| SNR | 40.0 dB | |
Camera Data |
||
|---|---|---|
| Interface | GigE | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 1 input(opto-isolated)，1 output(opto-isolated) ，1 bidirectional configurable non-isolated I/O, 1 RS232 | |
| Power Supply | 9-24 VDC | |
Design |
||
|---|---|---|
| Dimension(L x W x H) |
F-Mount:74 mm × 74 mm × 80.1 mm M58: 74 mm × 74 mm × 74.3 mm |
|
| Lens Mount | F-Mount / M58 | |
| Working Temperature | 0- 50°C（Operating），-30- 70°C（Storage） | |
| Weight |
F-Mount：600g M58：550g |
|
Software Environment |
||
|---|---|---|
| Driver , SDK | LEO Series Camera Secondary Development Kit（iDatum）or Third-party Software meeting with GigE Vision Protocol | |
| Operating System | Windows、Linux | |
| Conformity | GigE Vision , GenICam | |
