Information |
||
|---|---|---|
| PD No. | CP-1716 | |
| PD Line | LEO Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Sony | |
| Sensor | IMX290 | |
| Shutter | Rolling Shutter | |
| Sensor Size | 1/2.8" | |
| Sensor Type | CMOS | |
| Resolution | 1920 px x 1080 px | |
| Pixel size | 2.9 μm x 2.9 μm | |
| Frame Rate | 56 fps | |
| Mono/Color | Color | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 90.0 dB | |
| Signal-to-Noise Ratio (typical) | 41.0 dB | |
Camera Data |
||
|---|---|---|
| Interface | GigE | |
| Pixel Bit Depth | 8 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O |
1 input(non-isolated)， 1 output(non-isolated) , 1 bidirectional custom non-isolated I/O |
|
| Power Supply | PoE or 9-24 VDC | |
Design |
||
|---|---|---|
| Design | Compact industrial design | |
| Dimension (L x W x H) | 42 mm x 29 mm x 29 mm | |
| Lens Mount | C-mount | |
| Working Temperature | 0 - 50°C（Operating），-30 - 70°C（Storage） | |
| Weight（Typical） | 76g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | LEO Series Camera Secondary Development Kit（iDatum）or Third-party Software meeting with GigE Vision Protocol | |
| Operating System | Windows，Linux | |
| Conformity | GigE Vision and GenICam | |
