Information |
||
|---|---|---|
| PD No. | CP-0704 | |
| PD Line | LEO Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor |
Sony |
|
| Sensor | IMX297 | |
| Shutter | Global Shutter | |
| Sensor Size | 1/2.9" | |
| Sensor Type | CMOS | |
| Resolution | 720 px x 540 px | |
| Pixel size | 6.9 μm x 6.9 μm | |
| Frame Rate | 126.5 fps | |
| Mono/Color | Mono | |
| Pixel Format | Mono 8/10/10Packed/12/12Packed | |
| Exposure Time |
UltraShort exposure mode: 1μs to 14μs Standard exposure mode: 15μs to 10s |
|
EMVA Data |
||
|---|---|---|
| Dynamic range | 74 dB | |
| SNR | 41 dB | |
Camera Data |
||
|---|---|---|
| Interface | GigE | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O |
1 input(opto-isolated)， 1 output(opto-isolated), 1 bidirectional custom non-isolated I/O |
|
| Power Input |
PoE is optional / 9-24 VDC
|
|
Design |
||
|---|---|---|
| Design | Compact industrial design | |
| Dimension (L x W x H) | 29 mm x 29 mm x 42 mm | |
| Lens Mount | C-mount | |
| Working Temperature | 0 - 50°C（Operating），-30 - 70°C（Storage） | |
| Weight（Typical） | 76g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | LEO Series Camera Secondary Development Kit（iDatum）or Third-party Software meeting with GigE Vision Protocol | |
| Operating System | Windows，Linux | |
| Conformity | GigE Vision and GenICam | |
