Information |
||
---|---|---|
PD No. | LEO 5000S-60UC-BC | |
PD Line | LEO Series |
Sensor |
||
---|---|---|
Sensor Vendor | Sony | |
Sensor | IMX 264 | |
Shutter | Global Shutter | |
Sensor Size | 2/3" | |
Sensor Type | CMOS | |
Resolution | 2448 × 2048 | |
Pixel size | 3.45 μm x 3.45 μm | |
Frame Rate | 60 fps | |
Mono/Color | Color |
EMVA Data |
||
---|---|---|
Dynamic range | 72.0 dB | |
Exposure time | 15 μs ~ 10 s;UltraShort exposure mode(1 μs to 14 μs) |
Camera Data |
||
---|---|---|
Interface | USB3.0 | |
Pixel Bit Depth | 8 / 10 / 12 bits | |
Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
I/O | 2 bidirectional configurable I/O(without opto-isolated) | |
Power Supply | 5 VDC |
Design |
||
---|---|---|
Design | Compact industrial design | |
Dimension (L x W x H) | 29 mm × 29 mm × 31.3 mm | |
Lens Mount | C-Mount | |
Working Temperature | 0- 50°C(Operating),-30- 70°C(Storage) | |
Weight | 37g |
