Information |
||
|---|---|---|
| PD No. | MARS2048G-L59GM | |
| PD Line | Mars Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Gpixel | |
| Sensor Type | CMOS | |
| Resolution | 2048 px x 4 px | |
| Pixel size | 7 μm x 7 μm | |
| Line Rate | 59 K | |
| Mono/Color | Mono | |
EMVA Data |
||
|---|---|---|
| Signal-to-Noise Ratio (typical) | 39.6 dB | |
| Dynamic range (typical) | 65.5 dB | |
| Exposure Time | 8μs~100ms | |
Camera Data |
||
|---|---|---|
| Interface | GigE (1000 Mbit/s) | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 12-pin Hirose connector provides power and I/O;2 differential/single-ended inputs, 1 differential configurable input or output, 1 high-speed optocoupler single-ended input, 1 GPIO configurable input or output | |
| Power Supply | DC12V~24V | |
Design |
||
|---|---|---|
| Dimension (L x W x H) | 29 × 44 × 58 mm | |
| Lens Mount | C-Mount | |
| Working Temperature | -30- 50°C（Operating），-30- 80°C（Storage） | |
| Weight（Typical） | 100g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | Mars Series Camera Secondary Development Kit（iCentral）or Third-party Software meeting with GigE Vision Protocol | |
| Operating System | Windows，Linux | |
| Conformity | GigE Vision / GenICam | |
