Information |
||
|---|---|---|
| PD No. | iBOOSTX-100CUVC410M | |
| PD Line | iBoostX Series | |
Sensor |
||
|---|---|---|
| Sensor type | InGaAs | |
| Sensor | 4.2MP / GSENSE2020BSI(M,UV,RS) | |
| Sensor Size | 1.2"(13.31x13.31) | |
| Resolution | 2048 x 2048 | |
| Pixel Size | 6.5 x 6.5 μm | |
| FPS |
100@2048 x2048(11-bit ADC) 100@1024 x1024(11-bit ADC) |
|
| G light sensitivity | 1.1x108(e-/((W/m2).s))Peak QE 94% @550nm | |
| Dark current | 0.21(e-/s/pix) @-20C | |
| Spectral Range | 200-1100nm | |
EMVA Data |
||
|---|---|---|
| Dynamic range (typical) | 65.58dB | |
| Signal-to-Noise Ratio (typical) | 34.83dB | |
| Exposure Time | 12μs~1h | |
Camera Data |
||
|---|---|---|
| Interface | Cameralink | |
| Pixel Bit Depth | 8 Bit / HDR 16 Bit | |
| I/O | 1 opto-coupler isolated input, 1 opto-coupler isolated output, 2 GPIOs | |
| Power Supply | DC12V，3A | |
Design |
||
|---|---|---|
| Dimension | 80mm×80mm×107mm | |
| Lens Mount | C-mount | |
| Operating Temperature | -10~ 50℃ (Working)，-20~ 60℃ (Storage) | |
Software Environment |
||
|---|---|---|
| Operating System | Windows 7 / 8 /10 /11(32 & 64 位)，Mac OS，Linux | |
