LEO 64006LWT-50GM
1、0.3MP @50 fps
2、Adopts GigE interface and max. transmission distance of 100 meters without relay
3、Two temperature measurement ranges are optional, support single-area and multi-area temperature measurement alarm settings
4、Long Wave Infrared Camera - High Sensitivity Uncooled Vanadium Oxide Detector
Inquire now
Shop now
Product Description
Technical Drawing
Documents & Downloads

Information

PD No. LEO 64006LWT-50GM
PD Line LEO Series

Sensor

Resolution 640 px x 512 px
Sensor Technology Uncooled VOx Detector
Pixel Size 17 μm x 17 μm
Frame Rate 50 fps
NETD <50 mk(F1.0,30℃)
Response Time <10 ms
Image Format Mono 16/32,YUV422
Pseudo-color Mode White Hot, Black Hot, Fusion 1, Rainbow,Fusion 2, Ironbow 1, Ironbow 2, Sepia, Color 1, Color 2, Ice Fire, Rain, Green Hot, Red Hot
Image Processing Supports Brightness, Sharpness, Gamma Correction
Temperature Range -20℃ -150℃ /0℃ -550℃
Temperature Accuracy Max (±2℃ / ±2% of reading)
Temperature Distance Up to 5 m (@target size 0.1 × 0.1 m2)

Lens Data

EFL 6.3 mm
FOV 88.5° × 73.2°
M.O.D 0.6m
Aperture 1.0

Camera Data

Interface GigE
Digital I/O Opto-isolated input x 1, opto-isolated output x 1, and bi-directional custom non-isolated I/O x 1
Power Input DC 9-24V
Power Consumption 12V @2.8W

Design

Dimension(L x W x H) 48 mm x 48 mm × 121.4 mm
Weight 370g
Temperature -20- 50°C(Working)
-30~70 °C(Storage)

Software Environment

Driver LEO Series Camera Software Suite (iDatum)
Operating System Windows, Linux
Conformity GigE Vision, GenICam

Product Specification

LEO Series Industrial Cameras User Manual

LEO Series Industrial Cameras SDK iDatum
