Information |
||
|---|---|---|
| PD No. | iBOOSTX-726CSW33M-CM | |
| PD Line | iBoostX Series | |
Sensor |
||
|---|---|---|
| Sensor Type | InGaAs Buit-in TEC | |
| Sensor Size | 3/4" | |
| Resolution | 640 × 512 | |
| Pixel Size | 15 x 15 μm | |
| Frame Rate [Fps] | 726 | |
| Exposure time | 23.81μs-1s | |
| Spectral Range | 0.9μm - 1.7μm | |
EMVA Data |
||
|---|---|---|
| Dynamic range | TBD | |
| SNR | TBD | |
| QE | 75%@1350nm | |
| Dark current | 30fA@0.1V&18℃ | |
Camera Data |
||
|---|---|---|
| Interface | Cameralink Full | |
| Pixel Bit Depth | 12 Bit | |
| I/O | One opto-isolated input, one opto-isolated output, two non-isolated input and output | |
| Power Supply | DC12V | |
Design |
||
|---|---|---|
| Dimension | 68 × 68 × 90.3 mm (485g) | |
| Lens Mount | C-mount | |
| Operating Temperature | -40~85 °C (Storage), -30~60°C (Working) | |
Software Environment |
||
|---|---|---|
| Operating System | Windows | |
