Information |
||
|---|---|---|
| PD No. | iBOOSTX-257GSW32M-SA | |
| PD Line | iBoostX Series | |
Sensor |
||
|---|---|---|
| Sensor Type | InGaAs | |
| Sensor | Sony IMX991-AABA-C Buit-in TEC | |
| Sensor Size | 1/4" | |
| Resolution | 640 × 512 | |
| Pixel Size | 5 x 5 μm | |
| Frame Rate [Fps] |
12Bit:137.1 @640 x 512 / 258.6 @320 x 256 8 Bit: 257.8 @640 x 512 / 486.1 @320 x 256 |
|
| Exposure time | 15μs-60s | |
| Spectral Range | 0.4μm - 1.8μm | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 59.7dB | |
| SNR | 52.39dB | |
| Sensitivity | 121mV | |
| Dark current | 383e/s(0℃) 510e/s(10℃) 638e/s(20℃) | |
Camera Data |
||
|---|---|---|
| Interface | GigE | |
| Pixel Bit Depth | 8 Bit / 12 Bit | |
| I/O | One opto-isolated input, one opto-isolated output, two non-isolated input and output | |
| Power Supply | DC12V | |
Design |
||
|---|---|---|
| Dimension | 80 × 80 × 45.5 mm (<390g) | |
| Lens Mount | C-mount | |
| Operating Temperature | -40~85 °C (Storage), -20~60°C (Working) | |
Software Environment |
||
|---|---|---|
| Operating System | Windows，Linux | |
