iBOOST20GSW05KM
  • 512*1 @20KHz
  • Adopts GigE interface to transmit data
  • Support Windows
Inquire now
Shop now
Product Description
Technical Drawing

Information

PD No. iBOOST20GSW05KM
PD Line iBOOST Series

Sensor

Sensor Type InGaAs
Resolution 512 × 1
Pixel size 25 μm * 25 μm
Line Rate 20kHz
Spectral Range 0.9μm to 1.7μm

EMVA Data

Dynamic range ≥62.3dB
Signal-to-Noise Ratio (typical) ≥48.4dB

Camera Data

Interface GigE
Pixel Bit Depth 14bit, 12bit, 10bit, 8bit
Power Supply DC 12 V±2V

Design

Dimension 60×50×62.3mm
Lens Mount C-mount
Working Temperature -10- 60°C(Operating),-20- 70°C(Storage)
Weight(Typical) <240g

Software Environment

Operating System Windows
