iBOOST134CSWC130M
  • 1.3MP @134fps
  • Adopts CameraLink interface to transmit data
  • Support Windows
Inquire now
Shop now
Product Description
Technical Drawing

Information

PD No. iBOOST134CSWC130M
PD Line iBOOST Series

Sensor

Sensor Type InGaAs
Resolution 1280×1024
Pixel size 5 μm * 5 μm
Frame Rate 134fps
Spectral Range 0.4μm to 1.7μm

EMVA Data

Dynamic range 56dB
Signal-to-Noise Ratio (typical) 51dB

Camera Data

Interface CameraLink Base(SDR)
Pixel Bit Depth 8bit/10bit/12bit
Synchronization

● CameraLink_CC

● Free Run

Power Supply DC 12 V

Design

Dimension 72×76×65.6mm
Lens Mount C-mount
Working Temperature -20- 50°C(Operating),-30- 70°C(Storage)

Software Environment

Operating System Windows
