iBOOST10CSW05KM
  • 512*1 @10KHz
  • Adopts CameraLink interface to transmit data
  • Support Windows
Inquire now
Shop now
Product Description
Technical Drawing

Information

PD No. iBOOST10CSW05KM
PD Line iBOOST Series

Sensor

Sensor Type InGaAs
Resolution 512 × 1
Pixel size 25 μm * 25 μm
Line Rate ≤10kHz
Spectral Range 0.9μm to 1.7μm

EMVA Data

Dynamic range ≥69.8dB
Signal-to-Noise Ratio (typical) ≥46.6dB

Camera Data

Interface CameraLink Base(SDR)
Pixel Bit Depth 14bit, 12bit, 10bit, 8bit
Synchronization

● CameraLink_CC

● Free Run

Power Supply DC 12 V±2V

Design

Dimension 60×50×53.2mm
Lens Mount C-mount
Working Temperature -10- 60°C(Operating),-20- 70°C(Storage)
Weight(Typical) 300g

Software Environment

Operating System Windows
