Information |
||
|---|---|---|
| PD No. | GAL-5000-60ucNIR | |
| PD Line | GAL Galaxy Series | |
Sensor |
||
|---|---|---|
| Shutter | Global Shutter | |
| Sensor Size | 2/3 " | |
| Sensor Type | CMOS | |
| Resolution | 2592 px x 2056 px | |
| Pixel Size | 3.4μm x 3.4μm | |
| Frame rate | 60 fps | |
| Color | Color+NIR | |
EMVA Data |
||
|---|---|---|
| Dynamic range | > 72.0 dB | |
Camera Data |
||
|---|---|---|
| Interface | USB3.0 interface | |
| Pixel bit depth | 8/12 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 1 input(opto-isolated)， 1 output(opto-isolated), 1 bi-directional custom non-isolated I/O | |
| Power Supply | USB3.0 power supply | |
Design |
||
|---|---|---|
| Dimension | 38 mm x 38 mm x 49 mm | |
| Lens Mount | C-mount | |
| Working Temperature | 0-60 ° C (working) | |
Software Environment |
||
|---|---|---|
| Driver and SDK | GAL series camera secondary development kit | |
| Operating System | Windows | |
