| PD No. | iVa25CP3308M | |
| PD Line | iVaster Series | |
Camera Data
|
|
||
|---|---|---|
| Resolution | 320×256 | |
| Detector Type | Cooled MCT | |
| Pixel Size | 30μm | |
| Video Interface | CameraLink | |
| Communication Interface | 1 RJ45 10/100M auto-negotiating Ethernet port, 1 RS422 interface | |
| Network Protocol |
IPv4,HTTP,HTTPS,QoS,FTP,SMTP,UPnP,SNMP,DNS,DDNS, NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP |
|
| Platform Integration | ONVIF、GB28181、SDK | |
| Pseudocolor options |
Multiple pseudocolor options including Black Hot, White Hot, Rainbow, etc. (18 modes in total) |
|
| Simultaneous Video Previews | Supports up to 20 video streams | |
| User Management | Supports up to 20 users with 2 levels: Administrator and Regular User | |
| Browser Compatibility | Compatible with IE and Chrome browsers; supports both Chinese and English | |
| Intelligent Detection |
Supports intelligent video analysis features such as Tripwire, Intrusion, and Area Entry Detection |
|
| Alarm Linkage | Recording/Snapshot/Email/Alarm Output | |
| Video Compression Standard | H.264/H.265 | |
| Main Stream | 25fps(1280×1024,1024×768) | |
| Sub Stream | 25fps(640×512) | |
| Power Input | DC24V | |
| Power Consumption @25° C | Max ≤ 22W | |
| Operating Temperature | -20℃～ +50℃ (Working) | |
