Information |
||
|---|---|---|
| PD No. | iBOOST134USWC130M | |
| PD Line | iBOOST Series | |
Sensor |
||
|---|---|---|
| Sensor Type | InGaAs | |
| Resolution | 1280×1024 | |
| Pixel size | 5 μm * 5 μm | |
| Frame Rate | 134fps | |
| Spectral Range | 0.4μm to 1.7μm | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 56dB | |
| Signal-to-Noise Ratio (typical) | 51dB | |
Camera Data |
||
|---|---|---|
| Interface | USB3.0 | |
| Pixel Bit Depth | 8bit/10bit/12bit | |
| Power Supply | DC 12 V | |
Design |
||
|---|---|---|
| Dimension | 52mm×52mm×54.8mm | |
| Lens Mount | C-mount | |
| Working Temperature | -20- 50°C（Operating），-30- 70°C（Storage） | |
Software Environment |
||
|---|---|---|
| Operating System | Windows | |
